CURT 11656 Class 1 Fixed-Tongue Trailer Hitch with 3/4-Inch Trailer Ball Hole for Select Volkswagen Vanagon
CURT class 1 trailer hitches are the lightest-duty hitches of our rear mount lineup. They are engineered for reliability, welded together with quality steel and blasted clean for a smooth finish. Tested to meet the strict demands of the industry, this CURT class 1 hitch has a capacity to tow up to 1,500 lbs. of gross trailer weight and 150 lbs. of tongue weight. This means it can handle a variety of small trailers such as single-axle utility trailers, canoe and kayak trailers, dirt bike trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). This class 1 hitch is a fixed-tongue hitch, having a fixed draw bar to accept a trailer ball rather than a receiver tube to accept a ball mount. Class 1 hitches are typically mounted on compact cars, full-size cars and some smaller crossover SUVs, minivans and compact SUVs. This particular hitch is designed to be a custom-fit trailer hitch for certain years of the Volkswagen Vanagon (except Syncro) (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). It features a square tube frame and comes with all necessary installation hardware. Each CURT class 1 hitch is co-cured with a liquid A-coat and a high-gloss black powder coat that provide a lasting defense against rust, wear and harmful UV rays.
CURT class 1 trailer hitches are the lightest-duty hitches of our rear mount lineup. They are engineered for reliability, welded together with quality steel and blasted clean for a smooth finish. Tested to meet the strict demands of the industry, this CURT class 1 hitch has a capacity to tow up to 1,500 lbs. of gross trailer weight and 150 lbs. of tongue weight. This means it can handle a variety of small trailers such as single-axle utility trailers, canoe and kayak trailers, dirt bike trailers and more (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc). This class 1 hitch is a fixed-tongue hitch, having a fixed draw bar to accept a trailer ball rather than a receiver tube to accept a ball mount. Class 1 hitches are typically mounted on compact cars, full-size cars and some smaller crossover SUVs, minivans and compact SUVs. This particular hitch is designed to be a custom-fit trailer hitch for certain years of the Volkswagen Vanagon (except Syncro) (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). It features a square tube frame and comes with all necessary installation hardware. Each CURT class 1 hitch is co-cured with a liquid A-coat and a high-gloss black powder coat that provide a lasting defense against rust, wear and harmful UV rays.
- Made w/A Vehicle-Specific Design For A Custom Fit
- Tested For Safety In Accordance w/SAE J684
- Precisely Welded For Superior Strength And Fit
- Fixed Drawbar Readily Accepts A 3/4 In. Trailer Ball Shank
- Protected By A Durable High-Gloss Black Powder Coat Finish
- Co-Cured In A Rust-Resistant Liquid Bonderite Coating
- Backed By A Limited Lifetime Warranty
- Made in USA [may include imported hardware]
Information:
Class 1 Fixed-Tongue Trailer Hitch with 3/4 Trailer Ball Hole; Rated to 1,500 lbs. gross trailer weight and 150 lbs. tongue weight; Engineered with a vehicle-specific design for a custom fit; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Fixed drawbar readily accepts a 3/4 trailer ball shank; Protected by a durable high-gloss black powder coat finish; Co-cured in a rust-resistant liquid A-coat, inside and out; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware)Application Summary:
| Year | Make/Model |
|---|---|
| 1980-1991 | Volkswagen Vanagon |
| Attributes | |
| Body Shape | Square |
| Box Height in Inches - XA | 13 |
| Box Length in Inches - XA | 46 |
| Box Width in Inches - XA | 13 |
| California Proposition 65 | No |
| Class ID | 1 |
| Country of Origin (Primary) | US |
| Drilling Required | No |
| Emission Code | Legal US |
| Finish | Gloss Black Powder Coat |
| Finish - XA | GLOSS BLACK POWDER COAT |
| Gross Trailer Weight | 1500 lbs. |
| Gross Trailer Weight (lbs.) | 1500 |
| Harmonized Tariff Code (Schedule B) | 8708998180 |
| Hazardous Material Code | N |
| Install Time | 30 Minutes |
| Item Class - XA | MFH |
| Item Height - XA | 2.500 |
| Item Length - XA | 46.040 |
| Item Width - XA | 6.300 |
| Life Cycle Status Code | Discontinued |
| Long Description | Class I Hitch |
| Main Body Shape | Square |
| NAFTA Preference Criterion Code | B |
| Parcel Allowed - XA | Yes |
| Position | Rear |
| Product Weight - XA | 15.000 |
| Rate Class - XA | 70.0 |
| Receiver Tube Size | No Receiver Tube, 1.250 in. |
| Retail Height - XA | 14.000 |
| Retail Length - XA | 47.000 |
| Retail Width - XA | 15.000 |
| SDR Required Flag | N |
| Shipping Weight - XA | 21.000 |
| Tariff 301 - XA | No |
| Tongue Weight (TW) | 150 LB |
| Tongue Weight(TW) | 150 LB |
| Visibility | Exposed |
| Warranty | Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| WC Tongue Weight | 150 |
| Weight Carrying Capacity | 1500 |
| Weight Carrying Capacity (WC) | 1,500 LB |
| Weight Carrying Capacity(WC) | 1,500 LB |
| Weight Distribution (WD) | n/a |
| Weight Distribution Tongue Weight (WDTW) | n/a |
| Weight Distribution Tongue Weight(WDTW) | n/a |
| Weight Distribution(WD) | n/a |
| GTIN | 00612314116560 |
